170
Choose the menu Multicast→Multicast Table→IPv6 Multicast Table to load the following page.
Figure 10-22 IPv6 Multicast Table
The following entries are displayed on this screen:
Search Option
Multicast IP: Enter the multicast IP ad
dress the desired entry must
carry.
VLAN ID: Enter the VLAN ID the desired entry must carry.
Port: Select the port number the desired entry must carry.
Type:
Select the type the desired entry must carry.
All: Displays all multicast IP entries.
Static: Displays all static multicast IP entries.
Dynamic: Displays all dynamic multicast IP entries.
Multicast IP Table
Multicast IP: Displays the multicast IP.
VLAN ID: Displays the VLAN ID.
Forward Ports: Displays the forward ports of the group.
Type: Displays the type of the group.
Note:
The max number of multicast entries is 256. The IPv4 multicast table and IPv6 multicast table
share the total entry number of 256.
