TP-Link JetStream L2 User Manual

203
The following entries are displayed on this screen:

Search Option
Source:
Select a Source from the pull-down list and click the
Search
button to view your desired entry in the Binding Table.
• All: All the bound entries will be displayed.
• Manual:
Only the manually added entries will be
displayed.
• Scanning:
Only the entries formed via ARP Scanning will
be displayed.
• Snooping: Only th
e entries formed via DHCP Snooping
will be displayed.

Binding Table
H
ost Name
/IP Address
/
MAC Address Select:
Click the Select button to quick-
select the corresponding entry
based on the Host Name/IP Address/MAC Address
you
entered.
Select:
Select the desired entry to modify the Host Name
/MAC
Address/VLAN ID/Port /Protect Type. It is multi-optional.
Host Name:
Allows you to view and modify the Host Name.
IP Address:
Displays the IP Address of the Host.
MAC Address:
Allows you to view and modify the MAC Address of the Host.
VLAN ID:
Allows you to view and modify the VLAN ID.
Port:
Allows you to view and modify
the number of port connected to
the Host.
Protect Type:
Allows you to view and modify the Protect Type of the entry.
Source:
Displays the Source of the entry.
Collision:
Displays the Collision status of the entry.
• Warning:
Indicates that the collision may be caused by the
MSTP function.
• Critical:
Indicates that the entry has a collision with the
other entries.
Note:
1. Among the entries with Critical collision level, the one with the highest Source priority will take
effect.
2. Among the conflicting entries with the same Source priority, only the last added or edited one
will take effect.
13.1.2 Manual Binding
You can manually bind the IP address, MAC address, VLAN ID and the Port number together in
the condition that you have got the related information of the Hosts in the LAN.
