Step Operation Description
4
Configure MAC
VLAN 10
On VLANMAC VLANMAC VLAN page, create MAC VLAN10 with
the MAC address as 00-19-56-8A-4C-71.
5
Configure MAC
VLAN 20
On VLANMAC VLANMAC VLAN page, create MAC VLAN10 with
the MAC address as 00-19-56-82-3B-70.
6
Port Enable Required. On the VLANMAC VLANPort Enable page, select and
enable Port 11 and Port 12 for MAC VLAN feature.
Configure switch B
Step Operation Description
1
Configure the
Link Type of the
ports
Required. On VLAN802.1Q VLANPort Config page, configure the
link type of Port 21 and Port 22 as GENERAL and TRUNK respectively.
2
Create VLAN10 Required. On VLAN802.1Q VLANVLAN Config page, create a
VLAN with its VLAN
ID as 10, owning Port 21 and Port 22, and
configure the egress rule of Port 21 as Untag.
3
Create VLAN20 Required. On VLAN802.1Q VLANVLAN Config page, create a
VLAN with its VLAN
ID as 20, owning Port 21 and Port 22, and
configure the egress rule of Port 21 as Untag.
4
Configure MAC
VLAN 10
On VLANMAC VLANMAC VLAN page, create MAC VLAN10 with
the MAC address as 00-19-56-8A-4C-71.
5
Configure MAC
VLAN 20
On VLANMAC VLANMAC VLAN page, create MAC VLAN10 with
the MAC address as 00-19-56-82-3B-70.
6
Port Enable Required. On the VLANMAC VLANPort Enable page, select and
enable Port 21 and Port 22 for MAC VLAN feature.
Configure switch C
Step Operation Description
1
Configure the
Link Type of the
ports
Required. On VLAN802.1Q VLANPort Config page, configure the
link type of Port 2 and Port 3 as GENERAL, and configure the link type
of Port 4 and Port 5 as ACCESS.
2
Create VLAN10 Required. On VLAN802.1Q VLANVLAN Config page, create a
VLAN with its VLAN ID as 10, owning Port 2, Port 3 and Port 5,
3
Create VLAN20 Required. On VLAN802.1Q VLANVLAN Config page, create a
VLAN with its VLAN ID as 20, owning Port 2, Port 3 and Port 4,
6.6 Application Example for Protocol VLAN
Network Requirements
Department A is connected to the company LAN via Port12 of switch A;
Department A has IP host and AppleTalk host;
