Frame Rate and Performance for the
Single- and Dual-Port Devices
The S1801e and S1802e encoders support H.264 and MJPEG video up to D1/30fps on all streams
simultaneously for up to 10Mbps.
The available video frame rates (frames per second) of each encoder are:
NTSC-1, 2, 3, 3.75, 5, 6, 7.5, 10, 15, or 30 fps
PAL-1, 2.5, 5, 6.75, 8.33, 12.5, or 25 fps
Encoders 1, 2 and 3 are H.264 and Encoder 4 is MJPEG.
A typical scenario would be using encoder 1 as the recorder, since it is the primary H.264 encoder.
Encoder 3 or 4 can be used for viewing or recording, depending if you want to view live video in
H.264 or MJPEG.
Supported Resolution
The following table lists the video resolutions supported by the S1801e and S1802e encoders.
Resolution NTSC PAL
CIF 352 × 240 352 × 288
2CIF 704 × 240 704 × 288
4CIF 704 × 480 704 × 576
D1 720 × 480 720 × 576
Supported Frame Rates
The following table lists the performance that each video encoder on the S1801e and S1802e
encoders can achieve with the H.264 compression mode using single-stream encoding. For other
encoding values, refer to the Nextiva Edge Devices Stream Performance document, available on
the Verint extranet: https://online.verint.com/.
Resolution NTSC PAL
CIF 30 fps 25 fps
2CIF 30 fps 25 fps
4CIF 30 fps 25 fps
D1 30 fps 25 fps
Chapter 1: S1800e Series Overview
Verint Video Intelligence Solutions
22
