3. Select one of the following:
(Single- and Dual-Port devices) RS-232/422/485.
(Multiport devices) RS-232.
4. In the Baud Rate list, select the data rate used by the serial equipment.
5. In the Parity list, select the parity bit used by the serial equipment. Parity bits determine if the
data has been sent accurately over the network.
6. In the Stop bits list, select the stop bits used by the serial equipment. Stop bits let the receiver
know that the byte being transmitted has ended.
7. In the Data bits list, select the data bits used by the serial equipment. Data bits represents the
number of bits in each data that is sent over the network. Eight data bits are universally used in
most applications.
8. (Single- and Dual-Port devices)In the Modelist, select the way the serial equipment interfaces
with the device.
9. Click Apply.
Configuring the RS-422/485 Serial Port
Use the following procedure to configure an RS-422/485 device using the Web Interface.
► Perform the following steps:
1. Start the Web Interface.
2. From the tree, select Configuration >Serial Port.
Chapter 5: Using the Web Interface for Configuration
Verint Video Intelligence Solutions
78
