Setting SConfigurator
Before you can use SConfigurator to discover devices on the network, you need to set the initial
parameters.
► Perform the following steps:
1.
Download the latest version of SConfigurator from:www.verint.com/manuals.
2. Extract the executable file (SConfigurator.exe) to the desktop.
3. Double-click SConfigurator.exe to start SConfigurator.
4. In the General tab, click Program Options.
5. Select the IP address of the correct LAN interface from IP Address of the PC list.
SConfigurator automatically detects the IPaddress unless you are using two Ethernet cards or
are using virtual private network (VPN).
6. Select Detect All Units on LAN.
SConfigurator will discover all devices connected to the same LAN as the PC and having the
same VSIP port as SConfigurator will be discovered, even those whose IP addresses are not
part of the same subnet as the computer. This parameter works only with the broadcast
detection method. SConfigurator automatically switches to broadcast, even if the Discovery IP
Address box displays the multicast address.
7. Ensure that the VSIP Port is 5510; otherwise, click Default. This port number must be the same
in SConfigurator and in the devices to be configured. The default VSIP port is 5510.
NOTE: VSIP ports 9541, 65500, and those under 1024 are reserved and should never be used,
not even for serial port, video, or audio communication. The maximum value is 65535.
8. Ensure that the Discovery IP Address is 255.255.255.255; otherwise, click Broadcast. The
communication method and associated IP address SConfigurator will use to detect Nextiva
devices on the network. Contact your system administrator to know which method your network
supports. Possible methods are:
Setting SConfigurator
53
