Verint Nextiva S1808e-A User Manual

Tiles
1 2 3 4 5 6
4CIF
D1
<= 1 Megapixela
4CIF
D1
4CIF
D1
4CIF
D1
3 x 2a CIF
2CIF
4CIF
D1
<= 1 Megapixela
CIF
2CIF
4CIF
D1
CIF
2CIF
4CIF
D1
CIF
2CIF
4CIF
D1
CIF
2CIF
4CIF
D1
CIF
2CIF
4CIF
D1
Multiport Supported Resolutions
The S1808e, S1808e-A, S1816e and S1816e-A encoders support H.264 and MPEG-4 video up to
4CIF/30 frames per second on all ports. The S1816e-SP and S1816e-SRare a cost effective
encoders and supports H.264 video up to 4CIF/15 frames per second on all ports and can be
configured in dual or triple stream modes.
The available video frame rates (frames per second) of each encoder are:
NTSC-1, 2, 3, 3.75, 5, 6, 7.5, 10, 15, or 30 fps
PAL-1, 2.5, 5, 6.75, 8.33, 12.5, or 25 fps
Encoders 1 and 2 are H.264 and Encoder 3 is MPEG4. You can customize each encoder to meet
the system requirements in terms of frame rate and resolution.
A typical scenario would be using encoder 1 as the recorder, since it is the primary H.264 encoder.
Encoder 2 or 3 can be used for viewing or recording, depending if you want to view live video in
H.264 or MPEG4.
The following table lists the video resolutions supported by the S1800e series multi-port encoders.
Resolution NTSC PAL
CIF 352 × 240 352 × 288
2CIF 704 × 240 704 × 288
4CIF 704 × 480 704 × 576
D1 720 × 480 720 × 576
Chapter 1: S1800e Series Overview
Verint Video Intelligence Solutions
24
