8. In the Stop bits list, select the stop bits used by the serial equipment. Stop bits let the receiver
know that the byte being transmitted has ended.
9. In the Data bits list, select the data bits used by the serial equipment. Data bits represents the
number of bits in each data that is sent over the network. Eight data bits are universally used in
most applications.
10. (Single- and Dual-Port devices)In the Operation Mode, select the way the serial equipment
interfaces with the device.
11. Click OK to close the Unit Configuration dialog box.
12. Click Exit.
Setting the H.264 Encoding Mode for the
S1816e-SP or S1816e-SR
The S1816e--SP and S1816e-SR supports H.264 and MPEG-4 video on all 16 ports and can be
configured in dual or triple stream modes. By default, the S1816e-SP is set to dual stream mode
consisting of a single high-performance H.264 stream and a single MPEG-4 stream per video input.
However, you can set it to triple stream mode consisting of two H.264 streams with lower resolution
and framerate and a single MPEG-4 stream per video input.
► Perform the following steps:
1. Start SConfigurator.
2. Select the Units tab, then click Discover.
3. Select the Nextiva device, and click Configure.
4. In the tree view, click Unit.
5. In the Unit Name box, from the Performance Mode list, select the H.264 streaming mode. You
can select from:
Setting the H.264 Encoding Mode for the S1816e-SP or S1816e-SR
61
