3. From the Motion Detection tab, you can set the values of the following parameters for each
video input:
State: Enable or disable motion detection on the video input.
Mask State:Enable or disable the use of the mask for motion detection. If disabled, all
macroblocks in the frame are checked for motion.
Mask:Type the numerical string to specify which macroblocks that will be analyzed for
motion. An empty string indicates that all macroblocks in the frame is checked.
Upper Thresh:The minimum number of macroblocks with motion in a frame to start an
alert. This value must be greater than or equal to Lower Thresh. The values range from 1 to
1320 (NTSC) or 1 to 1548 (PAL).
Lower Thresh:The maximum number of macroblocks with motion in a frame to stop an
alert. This value must be less than or equal to Upper Thresh. The values range from 1 to
1320 (NTSC) or 1 to 1548 (PAL).
Vector Length:The amount of motion in a given macroblocks that must be present to tag
this as in motion. The values range from 0 to 255.
Number of Frames:The number of consecutive frames that must be detected as a new
motion. The values range from 1 to 1000.
4. Click Apply.
Configuring the Decoder Properties
The S1800e series compact decoders support four to six H.264 video streams, displaying up to four
tiles on traditional CCTV monitors and up to six tiles on high-definition LCD or plasma monitors.
► Perform the following steps:
1. Start the Web Interface.
2. From the tree, select Configuration >Video.
Video Profile
87
www.verint.com/video_solutions
