Scope of delivery
WAGO-I/O-SYSTEM 750
Linux Fieldbus Coupler
The /images directory
The /images directory contains the following files:
• jffs2.img
Image of the file system in JFFS2 format. JFFS2 stands for Journalling
Flash File System, Version 2.
Copying the image is started from uboot using the TFTP protocol or
netflash.
• linux.flashme
Image of the operating system.
Copying the image is started from uboot using the TFTP protocol or
netflash.
•
ub.bin
Image of the boot loader (uboot).
Copying the image is started from uboot using the TFTP protocol or
netflash.
•
image.hex
Complete base image consisting of the file system, operating system, boot
loader and firmware loader.
Transfer to the Linux fieldbus coupler is done using the WAGO-IO-
Update windows program.
You will find further information on uboot in chapter 9 and on netflash in
chapter 4.5.6
The /IO-Update directory
You will find here the setup to install the WAGO-IO-Update windows
program.

WAGO 750 Series Specifications

General

Protection Class	IP20
Bus Couplers	PROFIBUS, CANopen, Ethernet
Modules	Digital Input, Digital Output, Analog Input, Analog Output
Mounting	DIN rail mounting
Voltage Supply	24 V DC (typical)
Communication Protocol	Depends on the bus coupler (e.g., PROFIBUS, CANopen, DeviceNet, Ethernet)
Digital Input Channels	Varies by module (e.g., 8, 16 channels)
Digital Output Channels	Varies by module (e.g., 8, 16 channels)
Analog Input Channels	Varies by module (e.g., 2, 4, 8 channels)
Analog Output Channels	1, 2, 4 channels (depending on module)
Width	12 mm, 24 mm (typical module widths)
Number of Channels	Varies by module type
Current Consumption per Channel	Varies by module type
