WAGO 750 Series User Manual

Board Support Package (BSP) • 75
Web-Based Management (WBM)
WAGO-I/O-SYSTEM 750
Linux Fieldbus Coupler
Dynamic Configuration
• BootP
Activates configuration via BootP
• DHCP
Activates configuration via DHCP
Save Configurations
If a user with root rights enters his name and the correct password and then
clicks on the SAVE CONFIGURATION button, the corresponding CGI file will
save the changed values in several different places of the Linux fieldbus
coupler. The new values will only be activated after a reboot of the Linux
fieldbus coupler because theEthernet interface is only initialized during a boot
process.
Note
If wrong values are entered, they cannot possibly be corrected again after a
reboot of the Linux fieldbus coupler since it is no longer possible to access
the Linux coupler. A correction of the values is then only possible via the
serial interface using the Linux console
(see chapter 4.3, 4.6.1 and 4.6.2).

WAGO 750 Series Specifications

General

Protection Class	IP20
Bus Couplers	PROFIBUS, CANopen, Ethernet
Modules	Digital Input, Digital Output, Analog Input, Analog Output
Mounting	DIN rail mounting
Voltage Supply	24 V DC (typical)
Communication Protocol	Depends on the bus coupler (e.g., PROFIBUS, CANopen, DeviceNet, Ethernet)
Digital Input Channels	Varies by module (e.g., 8, 16 channels)
Digital Output Channels	Varies by module (e.g., 8, 16 channels)
Analog Input Channels	Varies by module (e.g., 2, 4, 8 channels)
Analog Output Channels	1, 2, 4 channels (depending on module)
Width	12 mm, 24 mm (typical module widths)
Number of Channels	Varies by module type
Current Consumption per Channel	Varies by module type
