CANopen gateway
Wieland Electric GmbH | BA000970 | 11/2016 (Rev. F)
141
Module
no.
Diagnostic bit
(M2 … M5)
Emergency
cause
Emergency message
02
00
Secure I/O
modules
Reserved
01
Internal error: Internal tests failed
02
Reserved
03
Reserved
04
Configuration is incompatible or invalid
05
Output power supply not in permitted range
06
Reserved
07
Reserved
08
Two-channel evaluation of input 1-2: error de-
tected
09
Two-channel evaluation of input 3-4: error de-
tected
10
Two-channel evaluation of input 5-6: error de-
tected
11
Two-channel evaluation of input 7-8: error de-
tected
12 to 15
Reserved
16
Error of the external test signal at input 1.
Check whether there is a short-circuit to High
or a cabling error
17
Error of the external test signal at input 2.
Check whether there is a short-circuit to High
or a cabling error
18
Error of the external test signal at input 3.
Check whether there is a short-circuit to High
or a cabling error
19
Error of the external test signal at input 4.
Check whether there is a short-circuit to High
or a cabling error
20
Error of the external test signal at input 5.
Check whether there is a short-circuit to High
or a cabling error
21
Error of the external test signal at input 6.
Check whether there is a short-circuit to High
or a cabling error
22
Error of the external test signal at input 7.
Check whether there is a short-circuit to High
or a cabling error
23
Error of the external test signal at input 8.
Check whether there is a short-circuit to High
or a cabling error
24
Error: Short-circuit after high at output 1
25
Error: Short-circuit after low at output 1
26
Error: Short-circuit after high at output 2
27
Error: Short-circuit after low at output 2
28
Error: Short-circuit after high at output 3
29
Error: Short-circuit after low at output 3
30
Error: Short-circuit after high at output 4
