Wieland samos PRO COMPACT - Page 142

CANopen gateway
Wieland Electric GmbH | BA000970 | 11/2016 (Rev. F)
142
Module
no.
Diagnostic bit
(M2 … M5)
Emergency
cause
Emergency message
31
Error: Short-circuit after low at output 4
03
00
PROFIBUS
gateway
Reserved
01
Internal error: Internal tests failed
02
Reserved
03
Reserved
04
Configuration is incompatible or invalid
05
Module state input data
06
Module state output data
07 to 31
Reserved
04
00
CANopen
gateway
Reserved
01
Internal error: Internal tests failed
02
Reserved
03
Reserved
04
Configuration is incompatible or invalid
05
Module state input data
06
Module state output data
07 to 31
Reserved
05
00
EtherCAT
gateway
Reserved
01
Internal error: Internal tests failed
02
Reserved
03
Reserved
04
Configuration is incompatible or invalid
05
Module state input data
06
Module state output data
07 to 31
Reserved
06
00
Reserved
Reserved
01
Internal error: Internal tests failed
02
Reserved
03
Reserved
04
Configuration is incompatible or invalid
05 to 31
Reserved
07
00
Reserved
Reserved
01
Internal error: Internal tests failed
02
Reserved
03
Reserved
04
Configuration is incompatible or invalid
05 to 31
Reserved
