CANopen gateway
Wieland Electric GmbH | BA000970 | 11/2016 (Rev. F)
143
Module
no.
Diagnostic bit
(M2 … M5)
Emergency
cause
Emergency message
08
00
Reserved
Reserved
01
Internal error: Internal tests failed
02
Reserved
03
Reserved
04
Configuration is incompatible or invalid
05 to 31
Reserved
09
00
Other
EtherNet/IP,
Modbus/TC
P, PROFI-
NET IO
gateway
Reserved
01
Internal error: Internal tests failed
02
Reserved
03
Reserved
04
Configuration is incompatible or invalid
05
Module state input data
06
Module state output data
07 to 31
Reserved
10
00
Other ga-
teway
Reserved
01
Internal error: Internal tests failed
02
Reserved
03
Reserved
04
Configuration is incompatible or invalid
05 to 31
Reserved
14
00
Unsecure
IO
Reserved
01
Internal error: Internal tests failed
02
Reserved
03
Reserved
04
Configuration is incompatible or invalid
05
Output power supply not in permitted range
06 to 31
Reserved
NOTICE
The allocation of the diagnostic bits for M2 to M5 is as follows:
Bit 0
Bit 1
…
Bit 7
Bit 8
…
Bit31
M5.0
M5.1
…
M5.7
M4.0
…
M2.7
