Operation0520−1/A1
Winterthur Gas & Diesel Ltd.
4/ 4
2
3
VS
4
1
WCH02257
WCH01217
Fig. 2: Exhaust Valve / Pressure Element
1 Damper 3 Shim
2 Pressure element (tool 94259) 4 Top housing
VS Maximum exhaust valve stroke
Operation with Exhaust Valve Control Unit Cut Out
