Operation
4002−2/A1
Winterthur Gas & Diesel Ltd.
19/ 37
Item Function Effect / Procedure
12 Manual lubrication start Move the cursor to the related button, then push the
rotary button to start manual lubrication. To select a
specified cylinder, see item 13.
13 Manual lubrication to
specified cylinder
The operator can select a cylinder (1 to 6) or set the
value to 100 for all cylinders. To start the manual
lubrication, see item 12.
14 Number of manual lubrication
pulses
Range 0 to 100
15 Operating Mode Shows the operating mode status. When the related
mode is active, the green indicator is on.
3.9.1 Speed/Load Mode Description
The number of revolutions until the next lubrication pulse is calculated in relation to
the set parameters. The values for the dry protect mode are set during the
commissioning. When the value is less than the set Dry Protect parameter (12), the
speed/ load mode becomes active. This is the standard mode during usual operation.
For more data about the Mode Dry Protect, see paragraph 3.8.2.
3.9.2 Dry Protect Mode Description
The number of revolutions until the next lubrication pulse is calculated in relation to
the set parameters. The values for the dry protect mode are set during the
commissioning. When the calculated value is more than the set dry protect parameter,
the dry protect mode becomes active.
Local Control Panel / Local Display Unit (LDU−20)
2015-12
