Operation7218−2/A1
Winterthur Gas & Diesel Ltd.
2/ 2
WCH02575
DRIVING END
I
Low Feedrate Bush
High Feedrate Bush
WCH02612
WCH02613
WCH03153
3 or 4
4 or 3
1
Pipes to lubrication
quills not shown
2
5
I
Fig. 1: Cylinder Lubricating Pump
1 Cylinder lubricating pump 4 High feed rate bush
2 Stroke adjustment screw 5 Screw
3 Low feed rate bush
2015-03
Cylinder Lubrication
