Operation80161/A1
Winterthur Gas & Diesel Ltd.
10/ 10
DRIVING END
WCH02301
1
2
3
1
3
Fig. 6: Servo Oil Rail
1 Screw plug 3 Drain pipe (to square collector)
2 Servo oil rail
2015-03
Lubricating Oil System
