Operation9362−1/A1
Winterthur Gas & Diesel Ltd.
2/ 2
4
WCH02527
13
FREE END
FUEL SIDE
10, 11
DATA FOR SIX
CYLINDERS
2
8
5
9
12
14
3
1
7
DRIVING END
6
Fig. 1: ECS electronic components
1 Rail unit 8 Terminal box E89
2 Terminal box E10 9 Terminal box E89.01 to E89.0x
3 Terminal box E20 10 Control box E90
4 Local control box E25 11 Control box E95
5 Terminal box E28 12 Terminal box E95.41 to E95.4x
6 Terminal box E31 and E32 13 Terminal box E95.21 to E95.2x
7 Terminal box E85.0 to E85.4 14 Terminal box E98
2014
Location of ECS Electronic Components
