WinGD X72 - Page 80

Operation0250−2/A1
Winterthur Gas & Diesel Ltd.
2/ 4
Media Unit Location Signal No.
(1)
Func-
tion
(2)
Type of
signal
( 3)
Setting
value
[bar or _C]
Time
Interval
[sec]
Oil mist Concentration Crankcase AS2401A ALM H − 0
AS2401S SLD H − 60
Failure Detection unit XS2411A ALM F − 0
Turbocharger Oil (TC ABB A100) Pressure Inlet PT2611−12A ALM L 1.0 bar 5
See Note (13) SLD L 0.8 bar 60
PS2611-12S SHD L 0.6 bar 5
Temperature Housing outlet TE2601-02A ALM H
110_C
0
SLD H
120_C
60
Turbocharger Oil (TC ABB A100) Pressure Inlet PT2611-12A ALM L 1.3 bar 5
(independent TC lube oil supply) See Note (13) SLD L 1.1 bar 60
PS2611-12S SHD L 0.9 bar 5
Temperature Housing outlet TE2601-02A ALM H
130_C
0
SLD H
140_C
60
Turbocharger Oil (TC MET MHI) Pressure Inlet PT2611-12A ALM L 0.7 bar 5
See Note (13) SLD L 0.6 bar 60
PS2611-12S SHD L 0.4 bar 5
Temperature Housing outlet TE2601-02A ALM H
85_C
0
SLD H
90_C
60
Torsional vibration damper
(steel spring damper)
Pressure Damper inlet PT2711A ALM L 2.2 bar (17) 0
Axial vibration damper oil Pressure Chamber rear PT2721A ALM L 1.7 bar 60
Chamber front PT2722A ALM L 1.7 bar 60
Cylinder Lubricating Oil Pressure Servo oil pressure −
free end
PT2041A A L 40.0 bar 3
A H 75.0 bar 3
Fuel Temperature
(4)
Upstream of the
supply unit
TE3411A ALM H
50_C to
160_C
0
ALM L
20_C to
130_C
0
(see 0710−1 Viscosity-Temperature
Diagram)
Pressure Upstream of the
supply unit
PT3421A ALM L 7.0 bar 0
Viscosity (4) Upstream of the
supply unit
(5)
ALM H 20 cSt 0
ALM L 13 cSt 0
Temperature Downstream of the
fuel pump
(12)
TE3431−32A ALM D
±30_C
30
Fuel Leakage Monitoring Level Rail/supply unit (7)
(7)
ALM H max. 0
2017−04
Alarms and Safeguards at Continuous Service Power
