Maintenance
1132−2/A2
Winterthur Gas & Diesel Ltd.
9/ 19
51) Connect the thrust device (94110,
Fig. 11) to the HP oil pump (94931).
52) Apply 1040 bar pressure to the thrust
device.
53) Carefully loosen the screw (5).
54) Slowly release the pressure to zero in
the thrust device (94110) refer to
9403−2.
55) Put the piston (3) in position.
56) Remove the thrust device (94110).
Note: To remove the main bearing cover
No. 1, refer to paragraph 3.
2016
Main Bearing − Removal and Installation
Fig. 11
WCH03014
5
3
94110
THRUST DEVICE 94110
To Next Page
