1126700 SmartPAC 2 User Manual
5-52 Program Mode
Enabling or Disabling All Sensors
When you access the Sensor On/Off Status screen, a message is displayed on the second line
of the screen beneath the screen title indicating whether sensors are enabled or disabled. If the
message is SENSORS ENABLED, the F5 function key is labelled “Disable All Sensors.” If
the message is SENSORS DISABLED, F5 is labelled “Enable All Sensors.”
When the message is SENSORS ENABLED, SmartPAC 2 is communicating with all the
sensors that are programmed and turned on. When the message is SENSORS DISABLED,
SmartPAC 2 is not communicating with the sensors.
To enable or disable all sensors, do the following:
1. On the Sensor On/Off Status screen, press F5.
If the SENSORS DISABLED message is displayed, F5 is labelled “Enable All Sensors,”
and pressing F5 enables all the sensors.
If the SENSORS ENABLED message is displayed, F5 is labelled “Disable All Sensors,”
and pressing F5 disables all the sensors.
2. Press RESET to return to the Main Program Menu.
Turning a Sensor Off or On
To turn a selected sensor Off or On, do the following:
1. On the Sensor On/Off Status screen, highlight the sensor you want.
2. Press ENTER to toggle between the OFF and ON settings until the setting you want is
displayed.
3. Press RESET to return to the Main Program Menu.
When a tool is loaded, or when SmartPAC 2 is powered up, all sensors are turned on and
enabled.
You can also enable or disable all sensors in Run mode. See DISABLE (ENABLE)
SENSORS, page 6-5.
• Sensors that show an N/U status have not been programmed. You cannot change their
status.
• If you turn a sensor Off on the Sensor On/Off Status screen, the sensor will turn on
when you reload the tool.
