SmartPAC 2 User Manual 1126700
SmartPAC to SmartPAC 2 Upgrade D-7
Table D-4. SmartPAC 1 to SmartPAC 2 Wiring Changes: Resolver Port
Original SmartPAC → SmartPAC 2
Signal Type Connector Pin Number Connector Pin Number Done (√)
SHIELD TB106 212
→
TB101 212
S1 TB106 213
→
TB101 213
S2 TB106 214
→
TB101 214
R1 TB106 215
→
TB101 215
S3 TB106 216
→
TB101 216
R2 TB106 217
→
TB101 217
S4 TB106 218
→
TB101 218
Table D-5. SmartPAC 1 to SmartPAC 2 Wiring Changes: Position Sensor (If Used)
Original SmartPAC → SmartPAC 2
Signal Type Connector Pin Number Connector Pin Number Done (√)
+V TB107 245
→
TB107 245
POS TB107 246
→
TB107 246
GND TB107 247
→
TB107 247
Table D-6. SmartPAC 1 to SmartPAC 2 Wiring Changes: DiProPAC, 8-Channel
Original SmartPAC → SmartPAC 2
Signal Type Connector Pin Number Connector Pin Number Done (√)
SENSOR 1 TB501 282
→
TB554 282
SENSOR 2 TB501 283
→
TB554 283
SENSOR 3 TB501 284
→
TB554 284
SENSOR 4 TB501 285 TB554 285
SENSOR 5 TB501 286 TB554 286
SENSOR 6 TB501 287 TB554 287
SENSOR 7 TB501 288 TB554 288
SENSOR 8 TB501 289 TB554 289
SEN. POWER TB501 290 TB554 290
GND TB501 291 TB554 291
