SmartPAC 2 User Manual 1126700
Introduction 1-7
SmartPAC 2 Specifications
SmartPAC 2 specifications are shown in Table 1-1.
Table 1-1. SmartPAC 2 Specifications
Equipment
Main enclosure: 12.76 x 11.53 x 5.28 in. (324 x 293 x 134 mm), NEMA 12,
shock mounted. Weight: 17.4 lbs.
Panel mount: 12.3 x 11.3 in. (312 x 287 mm)
Resolver: 0.75 in. (19 mm) keyed shaft; rated shaft loading: 200 lb. axial, 200
lb. radial
Electrical
Input: 115/230 ± 10% Vac 50/60 Hz, 50 VA
Input check circuit: 12-250 Vac or Vdc
Oper. Temp.
32° to 122° F (0° to 50° C)
Speed
7-800 SPM; 14-1600 SPM optional at reduced accuracy (see Options, below)
Accuracy
± 2/3° (± 1.33° for high speed version–see Options, below)
Counters
Good parts, strokes, 3 batch with presets (7 digits)
Number-of-hits-on-tool counter: counts all hits on tool; resettable to 0 after
maintenance
Display
10.4 in. (264 mm) color active matrix TFT liquid crystal display (LCD)
Brake Warning LED, Power LED
Memory
Allows storage of settings for 200 tools
Inputs/Outputs
Inputs for resolver, position sensor (resolver slippage detection),
input check circuit, remote reset input, setup mode input
USB, PS/2 and Ethernet RJ-45 connectors
Outputs for top stop, emergency stop: ratings 0-4 A resistive @ 120V max
(AC or DC); Normally open–Held closed. Fault condition or power off opens
relay(s)
Communications
Connects via Ethernet to local area network; data viewed via the Internet using
SmartView remote viewing utility; allows backup of programmed tool settings
to a network drive.
Options
DiProPAC provides up to 32 die protection sensor inputs
Power for electronic sensors (NPN only): 15 Vdc min., 100 mA total
DiPro Sensor Interface, DSI 2*: 5.88 x 5.41 x 3.42 in. (149 x 137 x 87 mm)
DiProPAC sensor-disabled output: open collector, 8 mA max.
ProCamPAC provides up to 16 programmable cam switch output channels
Programmable cam output assembly: NEMA 12, holds up to 8 outputs
Enclosure: 9 x 11 x 3.5 (229 x 279 x 89 mm) shock-mounted
Relay SPDT 0-3 A resistive @ 240V
DC solid state SPST 2A @ 5-60 Vdc
AC solid state SPST 1A @ 70-250 Vac
