Wintriss SmartPAC2 User Manual

1126700 SmartPAC 2 User Manual
D-10 SmartPAC to SmartPAC 2 Upgrade
Table D-11. SmartPAC 1 to SmartPAC 2 Wiring Changes: Remote Dual Op. Station Select
(Optional Remote Switch)
Original SmartPAC → SmartPAC 2
Signal Type Connector Pin Number Connector Pin Number Done (√)
OP STA 1 TB202 253
→
TB107 254
OP STA 2 TB202 254
→
TB107 253
GND TB202 256
→
TB107 250
Table D-12. SmartPAC 1 to SmartPAC 2 Wiring Changes: WPC Adjustment Lockout Switch
(Optional)
Original SmartPAC → SmartPAC 2
Signal Type Connector Pin Number Connector Pin Number Done (√)
LOCKOUT TB202 255
→
TB107 251
GND TB202 256
→
TB107 250
Table D-13. SmartPAC 1 to SmartPAC 2 Wiring Changes: Remote Reset (Optional)
Original SmartPAC → SmartPAC 2
Signal Type Connector Pin Number Connector Pin Number Done (√)
REMOTE RES TB203 257
→
TB107 249
GND TB203 258
→
TB107 250
Table D-14. SmartPAC 1 to SmartPAC 2 Wiring Changes: AutoSetPAC/WaveFormPAC,
2 or 4 Channel (Integration Only)
Original SmartPAC → SmartPAC 2
Signal Type Connector Pin Number Connector Pin Number Done (√)
GND TB102 240
→
TB103 240
+RXD2 TB102 241
→
TB103 241
-RXD2 TB102 242
→
TB103 242
+TXD2 TB102 243
→
TB103 243
-TXD2 TB102 244
→
TB103 244
