A-12 Preventive Maintenance Monitor
Using the PM Monitor in Run mode
How to Get into SmartPAC Run Mode
To get into Run mode, turn the Program/Run key to RUN.
A Tool Number Must Be Loaded Before Switching to Run Mode
If no tool number has been loaded, you cannot switch from Initialization mode or Program
mode to Run mode. A tool number must be loaded before SmartPAC will allow the press to
run.
If you try to switch to Run mode without a tool number loaded, you will get this error message
on your screen:
NO TOOL NUMBER HAS BEEN LOADED
If so, turn the Program/Run key to “PROG”. Press RESET to clear the error message. Then
load a tool number. Now turn the Program/Run key to “RUN”. The Run menu, shown below,
is the first display you see in Run mode. From this display you can access the PM Monitor
selection.
Before changing modes, make sure your screen shows the first display in the mode you are in. If
that display is not shown, nothing will happen when you turn the Program /Run key. In that case,
keep pressing the RESET key. When the first display in the mode is reached, you will instantly
switch to the new mode.
Figure A-13. “PM Monitor” Highlighted on SmartPAC 2 Run Menu
(Your list of options may be different, depending on the features you have installed.)
NOTICE
USE CURSOR KEYS TO
MAKE SELECTIONS.
PRESS ENTER TO ACCESS
SELECTION.
DISABLE SENSORS
COUNTERS
BRAKE MONITOR
DIE PROTECTION
CAM SWITCH
PM MONITOR
LOAD NEW TOOL
TOOL NUMBER 1234567
CHAIR BRACKET
SENSORS ENABLED
SENSOR 1
This alert message
appears at the
main Run menu
when a PM alert
condition is present.
Select PM Monitor
from this screen to
attend to the offending
item.
PM ALERT
PM MONITOR
