SmartPAC 2 User Manual 1126700
Preventive Maintenance Monitor A-13
Viewing and Modifying PM Alerts
1. Select “PM Monitor” from the first display in Run mode.
2. You will see the list of PM items that you previously assigned in Initialization. The first
item is highlighted in the next example. Use the cursor keys to view the other items on the
schedule. Currently the PM status for all items is “normal” (see display). This means that
none of the items has reached the limits set in Initialization.
Figure A-14. Run Mode Screen Showing PM Monitor in “Normal” Status Mode
You may notice that some of the current values do not update on every stroke while the
press is running. SmartPAC is keeping track of these items, but does not refresh the
display until the press actually stops.
USE CURSOR KEYS TO CHANGE SELECTION
PRESS ENTER TO SELECT, RESET WHEN DONE
CLUTCH VALVE
ALERT AT
CURRENT
2000 STARTS/STOPS
1001 STARTS/STOPS
YOUR PRESS NAME
STATUS IS NORMAL
PM MONITOR
SLIDE ADJ. MOTOR
ALERT AT
CURRENT
100 DIE CHANGES
75 DIE CHANGES
GIBS
ALERT AT
CURRENT
1000000 STROKES
458239 STROKES
MORE
notice that alert status
is "normal"
CLEAR
ALERT
F3
CHANGE
VALUE
F4
NOTICE
