SmartPAC 2 User Manual 1126700

SmartPAC to SmartPAC 2 Upgrade D-11

Table D-15. SmartPAC 1 to SmartPAC 2 Wiring Changes: SFI (Optional)

Original SmartPAC → SmartPAC 2

Signal Type Connector Pin Number Connector Pin Number Done (√)

+RXD1 TB102 235

→

TB103 235

-RXD1 TB102 236

→

TB103 236

TXD1 TB102 237

→

TB103 237

+TXD1 TB102 238

→

TB103 238

-TXD1 TB102 239

→

TB103 239

GND TB102 240

→

TB103 240

Table D-16. SmartPAC 1 to SmartPAC 2 Wiring Changes: MultiPAC (Special Port - Optional)

Original SmartPAC → SmartPAC 2

Signal Type Connector Pin Number Connector Pin Number Done (√)

+RXD3 TB103 224

→

TB104 224

-RXD3 TB103 225

→

TB104 225

TXD3 TB103 226

→

TB104 226

+TXD3 TB103 227

→

TB104 227

-TXD3 TB103 228

→

TB104 228

GND TB103 229

→

TB104 229
