SmartPAC 2 User Manual 1126700
SmartPAC to SmartPAC 2 Upgrade D-5
1. Referring to the sketch you made in step 3 of the Removing SmartPAC 1 and Mounting
SmartPAC 2 procedure (page D-3), feed all wires into SmartPAC 2 knockout holes and
secure all seal-tight connectors. See AC Wiring on SmartPAC 2, page D-12 for details on
wiring the AC input and ground connections.
2. Check to make sure that the positions of jumpers JP101 (Master or Slave) and JP102 (high
or low speed) and input check switch (S101) are the same as they were in SmartPAC 1.
Refer to Figure 2-7, page 2-13 for jumper and switch locations.
3. Paying careful attention to orientation, reinstall and rewire the DiProPAC (connector J112
in Figure 2-7) and ProCamPAC (connector J111) boards you removed in step 5 of the
Removing SmartPAC 1 and Mounting SmartPAC 2 procedure (page D-3). Skip this step if
you purchased SmartPAC 2 with ProCamPAC and DiProPAC already installed.
4. Referring to the appropriate wiring table (Table D-1 through Table D-16) and to the wiring
diagram in Figure 1 at the back of the manual, terminate all wires at their appropriate pin
locations. Re-cut and strip wires where necessary.
5. Make the appropriate wiring connections between DiProPAC and ProCamPAC boards, if
installed (see step 3), and DSI 2 and the Cam Output assembly. See Figures 9, 10, and 11
at the back of the manual.
6. If you plan to network your SmartPAC 2, run Cat 5 cable with an RJ-45 connector into the
enclosure.
7. Check your work, making sure that all wiring is correct, terminal screws are tight and
making an electrical connection, and all connectors and socketed ICs are seated.
8. Connect AC input wires and ground wire to SmartPAC 2 as shown in AC Wiring on
SmartPAC 2, page D-12.
DAMAGE TO BOARD FROM STATIC DISCHARGE
Ground yourself before touching circuit boards or chips by touching a large metal object
such as the press. Static electricity can destroy electronic components.
Failure to comply with these instructions could result in property damage.
The Cat 5 cable can share seal-tight conduit with a low-voltage line or it can be run
separately. Do not run the Cat 5 cable with high-voltage wiring.
DAMAGE TO BOARD FROM STATIC DISCHARGE
Ground yourself before touching circuit boards or chips by touching a large metal object
such as the press. Static electricity can destroy electronic components.
Failure to comply with these instructions could result in property damage.
CAUTION
NOTICE
CAUTION
