Xerox B310

Action Yes No
Step 6
1 Remove the right cover. See
Right cover removal.
2 Make sure that the JEXIT1
sensor cable is properly
connected to the controller
board.
Does the problem remain?
Go to step 7. The problem is solved.
Step 7
1 Enter the Diagnostics menu,
and then navigate to:
Printer diagnostics &
adjustments > Motor tests
2 Find the main motor (forward).
3 Open the front door, remove
the imaging unit, and then
close the front door.
4 Activate the motor test.
5 Open the rear door, and then
check if the fuser belt is
properly rotating.
Is the fuser belt properly rotating?
Go to step 9. Go to step 8.
Step 8
1 Remove the right cover. See
Right cover removal.
2 Make sure that the JMTR1
sensor cable is properly
connected to the controller
board.
Does the problem remain?
Go to step 9. The problem is solved.
Step 9
Replace the fuser. See Fuser
removal.
Does the problem remain?
Go to step 10. The problem is solved.
Step 10
Perform a print job.
Does the problem remain?
Go to step 11. The problem is solved.
Xerox
®
B310 Printer
Service Manual
79
Diagnostics and Troubleshooting
