SSeennssoorr ((FFuusseerr EExxiitt)):: PPaappeerr FFaaiilleedd TToo CClleeaarr JJaamm SSeerrvviiccee CChheecckk
Action Yes No
Step 1
1 Make sure that the fuser exit
area, rear door, and redrive
area are free of jammed paper
or paper fragments
2 Make sure that the rear door
can properly close.
3 Check the rear door for
damage.
Is the rear door functional and
free of damage?
Go to step 3. Go to step 2.
Step 2
1 Enter the Diagnostics menu,
and then navigate to:
Printer diagnostics &
adjustments > Sensor tests
2 Find the sensor (fuser exit).
3 Make sure that the sensor
actuator freely moves and is
not stuck.
Does the sensor status change
while toggling the sensor?
Go to step 5. Go to step 3.
Step 3
1 Remove the right cover. See
Right cover removal.
2 Make sure that the JEXIT1
sensor cable is properly
connected to the controller
board.
Does the problem remain?
Go to step 4. The problem is solved.
Step 4
Replace the rear door. See Rear
door removal.
Does the problem remain?
Go to step 5. The problem is solved.
Step 5
Replace the fuser. See Fuser
removal.
Does the problem remain?
Go to step 6. The problem is solved.
Step 6
Check the redrive for damage.
Is the redrive free of damage?
Go to step 8. Go to step 7.
