2-322
Phaser 7760 Color Laser Printer
012-945
Revised
Status Indicator RAP’s
012-945 Low Staples
The Low Staple Sensor turned ON just before the Staple Motor started running.
Initial Actions
• Check the Stapler Head connectors for connection failure.
• Check the staple remaining amount.
Procedure
Enter Service Diagnostics Menu: Printer Menu > Troubleshooting > Service Tools > Printer
Status Page > hold the Up and Down buttons simultaneously > Run Service Diagnostics >
OK. Actuate the Low Staple Sensor (PL 21.6). ‘LOW’ (staples available) is displayed.
YN
Check continuity between the Stapler Head and Finisher PWB (Figure 1). The continu-
ity check is OK.
YN
Repair the open circuit or short circuit.
Replace the Stapler Head (PL 21.6). If the problem continues, replace the Finisher PWB
(PL 21.12).
If the problem continues, replace the Finisher PWB (PL 21.12).
