Status Indicator RAP’s
024-942 Booklet Sheets Counts Over
Booklet Sheets Counts over.
Procedure
Procedure not available.
024-943 Booklet Low Staple
Booklet Low Stapler Low Staple signal detected just before Stapling operation.
Booklet Stapler Low Staple signal was detected at power On, at initialization, or when the Inter-
lock was closed.
Procedure
Supply the staples. The problem is resolved.
YN
Enter Service Diagnostics Menu: Printer Menu > Troubleshooting > Service Tools >
Printer Status Page > hold the Up and Down buttons simultaneously > Run Service
Diagnostics > OK. Actuate the Booklet Stapler Low Staple (Front/Rear). ‘LOW’ (sta-
ples available) is displayed.
YN
Check continuity between the Staple and Booklet PWB, and between the Booklet
PWB and Finisher PWB (Figure 1). The continuity check is OK.
YN
Repair the open circuit or short circuit.
Replace the Booklet Stapler Low Staple Front/Rear (PL 21.16). If the problem con-
tinues, replace the Finisher PWB (PL 21.12).
Replace the Finisher PWB (PL 21.12). If the problem continues, replace the Booklet PWB
(PL 21.12).
If the problem continues, replace the Finisher PWB (PL 21.12). If the problem persists, replace
the Booklet PWB (PL 21.12).
