Xerox Phaser 7760 Service Manual

January 2010
2-18
Phaser 7760 Color Laser Printer
003-588, 003-589
Revised
Status Indicator RAP’s
003-588 Paper Tray 3 Not Available
Paper Tray 3 not available.
Fault(s) 007-271, 007-282 may be declared.
Procedure
Turn the printer power Off, then On. The problem continues.
YN
Return to Service Call Procedures.
Check for Fault(s) 007-271, 007-282. There is a 007-271 fault declared.
YN
Go to RAP 007-281, Tray (2, 3, 4, 5) Lift Failure.
Go to RAP 007-271, Tray 3 Paper Size Sensor.
003-589 Paper Tray 4 Not Available
Paper Tray 4 not available.
Fault(s) 007-276, 007-283, 007-291 may be declared.
Procedure
Turn the printer power Off, then On. The problem continues.
YN
Return to Service Call Procedures.
Check for fault(s) 070-276, 007-291. There is a 007-276 fault declared.
YN
Go to RAP 007-281, Tray (2, 3, 4, 5) Lift Failure.
Go to RAP 007-276, Tray 4 Paper Size Sensor.
