Xerox Phaser 7760 Service Manual

January 2010
2-19
Phaser 7760 Color Laser Printer
003-590, 003-594
Status Indicator RAP’s
Revised
003-590 Paper Tray 5 not Available
Paper Tray 5 not available.
Fault(s) 007-277, 007-284, 007-293 may be declared.
Procedure
Turn the printer power Off, then On. The problem continues.
YN
Return to Service Call Procedures.
Check for fault(s) 007-277, 007-293. There is a 007-277 fault declared.
YN
Go to RAP 007-281, Tray (2, 3, 4, 5) Lift Failure.
Go to RAP 007-277, Tray 5 Paper Size Sensor.
003-594 Tray 1 (MPT) Broken
Tray 1 (MPT) Size Sensor Broken.
Procedure
Go to RAP 007-274, Tray 1 Paper Size Sensor.
