Phaser 8400/8500/8550/8560 Color Printer Service Manual 4-23
General Troubleshooting
Tray 4 Pick
2 Tray 4 Pick Interval
(us)
Reports the interval from the
time the engine software is
commanded to start the tray 4
pick process until the Tray 4
Pick sensor activates.
3 Tray 4 Transport
Interval (us)
Reports the interval from the
Tray 4 Pick sensor activation
until the Tray 3 Pick sensor
activates.
4 Tray 3 Transport
Interval (us)
Reports the interval from the
Tray 3 Pick sensor activation
until the Deskew sensor
activates.
Tray 3 Pick
2 Unused
3 Tray 3 Pick Interval
(us)
Reports the interval from the
time the engine software is
commanded to start the tray 3
pick process until the Tray 3
Pick sensor activates.
4 Tray 3 Transport
Interval (us)
Reports the interval from the
Tray 3 Pick sensor activation
until the Deskew sensor
activates.
Tray 2 Pick
2 Unused
3 Unused
4 Tray 2 Pick Interval
(us)
Reports the interval from the
time the engine software is
commanded to start the tray 2
pick process until the Deskew
sensor activates.
Tray 1 Pick
2 Unused
3 Unused
4 Tray 1 Interval (us) Reports the interval from the
time the engine software is
commanded to start the tray 1
pick process until the Deskew
sensor activates.
Paper Lead Edge Times (Continued)
R# Definition
Typical
Value
(8400)
Typical
Value
(8500/
8550/8560) Actions
