Phaser 8400/8500/8550/8560 Color Printer Service Manual 4-25
General Troubleshooting
Tray 4 Pick
2 Tray 4 Pick Trailing
Edge Interval (us)
Reports the interval from the
time the engine software is
commanded to start the tray 4
pick process until the Tray 4
Pick sensor deactivates.
Tray 3 Pick
3 Tray 3 Pick Trailing
Edge Interval (us)
Reports the interval from the
time the engine software is
commanded to start the tray 3
pick process until the Tray 3
Pick sensor deactivates.
Tray 2 Pick
2 Unused
3 Unused
Tray 1 Pick
2 Unused
3 Unused
Common
4 Deskew Trailing
Edge Interval (us)
Reports the interval from the
time the engine software is
commanded to start the
transfix process until the
Deskew sensor deactivates.
(part way through the paper
transfix motion).
5 Preheat Trailing
Edge Interval (us)
Reports the interval from the
time the engine software is
commanded to start the
transfix process until the
Preheat sensor deactivates.
(part way through the paper
transfix motion).
6 Strip Trailing Edge
Interval (us)
Reports the interval from the
time the engine software is
commanded to start the exit
process until the Strip sensor
deactivates (part way through
the paper exit motion).
Paper Trail Edge Times (Continued)
R# Definition
Typical
Value
(8400)
Typical
Value (8500/
8550/8560) Actions
