4-30 Phaser 8400/8500/8550/8560 Color Printer Service Manual
General Troubleshooting
Paper is picked and moved through either the duplex paper path to determine
the paper trailing edge bounce interval at each paper path sensor. R values
have alternate definitions or are unused depending on the pick tray and if
simplex or duplex path was selected.
Duplex Paper Sensor Bounce Times
R# Definition
Typical
Value
(8400)
Typical
Value
(8500/
8550/8560)
Actions
7 Exit Bounce
Interval (us)
Reports the interval during
which the Exit sensor bounces
following the passage of the
paper trailing edge during
duplex turnaround.
8 Duplex Deskew
Bounce Interval
(us)
Reports the interval during
which the Deskew sensor
bounces following the passage
of the paper trailing edge.
9 Duplex Preheat
Bounce Interval
(us)
Reports the interval during
which the Preheat sensor
bounces following the passage
of the paper trailing edge.
10 Duplex Strip
Bounce Interval
(us)
Reports the interval during
which the Strip sensor
bounces following the passage
of the paper trailing
11 Duplex Exit Bounce
Interval (us)
Reports the interval during
which the Exit sensor bounces
following the passage of the
paper trailing edge.
