Phaser 84000/8500/8550/8560 Color Printer Service Manual 6-7
Adjustments and Calibrations
N
o
t
e
When the tilt gear is disengaged, the two arrows on the left side of the
printer are pointing at each other.
s8500-063
Tilt Gear EngagedTilt Gear Disengaged
