Phaser 8400/8500/8550/8560 Color Printer Service Manual 8-35
Service Parts Disassembly
R
ep
l
acemen
t
N
o
t
e
Route the Stripper Solenoid harness through the right side frame
when replacing the Upper Duplex Guide. Also, verify that the solenoid
lever engages the hole in the Stripper Carriage.
s8500-099
Hole for
Solenoid Lever
Solenoid Lever
Upper Duplex Guide
