Phaser 8400/8500/8550/8560 Color Printer Service Manual 9-11
Parts Lists
Parts List 4.0 Motors, Gears, Solenoids, Clutches, and Fans
No. Name/Description Qty
Part Number
1 Preheater Lift Solenoid 1 121K44430 (8500/8550/8560)
2 Motor, Y-Axis Drive 1 127K56520
3 Pick Solenoid, Tray 1 1 121E20120
4 Head Tilt Solenoid 1 121K44480 (8500/8550/8560)
5 Gearbox, Media Drive with 2 Clutches,
Solenoid
1 401098480 (8400)
807E23090 (8500/8550/8560)
6 Tray Lift Motor Kit and Gear (plus item 10) 1 604K31810
7 Paper Path Cooling fan 1 119650580 (8400)
No longer orderable (refer to
service bulletin 655).
8 Electronics Module System Fan 1 119642680 (8400)
133K25010 (8500/8550/8560)
9 Compound Gear, Head Tilt 1 807E16060
10 Tray Lift Motor Kit and Gear (plus item 6) 1 604K31810
11 Electric Clutch, Wiper (Head Maintenance
Clutch)
1 033E05190
12 X-Axis Motor Assembly 1 127K53580
13 Drum Cooling Fan 1 119641780 (8400)
127E16010 (8500/8550/8560)
14 Gearbox and Motor, Process Drive 1 401100080 (8400)
005K12670 (8500/8550/8560)
15 Ground Clip, Pick Clutch 1 650442700 (8500/8550/8560)
To Next Page
