one location, the illustration changes to indicate the multiple locations and the required corrective
actions.
Tray 6 Fault Code Information
When a fault occurs, such as paper jams, open doors or covers, or a press malfunction, the press stops
printing and a message appears on the press UI.
The UI also displays a Faults button which provides information about the fault and detailed
instructions for correcting the fault.
Tip: Tray 6 faults are identified by the codes which start with the three-digit numbers 024 and
078.
TTrraayyss 66 aanndd 77 TTrroouubblleesshhoooottiinngg
TTrraayyss 66 aanndd 77 PPaappeerr JJaammss
Paper Jams When the Bypass is Installed on Trays 6 and 7
Tip: Always ensure that all paper jams, including any small, ripped pieces of paper, are cleared
before proceeding with any print jobs.
1. Remove the paper currently loaded in the Bypass (Tray 5).
2. Lift and open the Top Cover of the Bypass (Tray 5).
282
