Xerox WorkCentre 5024 Service Manual

06/2014
6-11
WC 5022/5024
6.1.14 Tray (Paper Feed)
General
Version 1.0
*1 : There is no 2 Sided for Plain Reload
*2 : IOT designed value: 23.55
6.1.14 Tray (Paper Feed)
6.1.14.1 Paper Trays
Paper Trays refer to all type of Trays that are pulled out towards the front.The Main Unit has
the MSI and the 250-sheet Paper Tray (1 level) as standard configuration.As field options, the
500-sheet Paper Tray (Single Tray Module: STM) and the 500-sheet 2 Level Paper Tray (2-
Tray Module: 2TM) are available. The MSI is installed on the left side of the IOT by standard.
6.1.14.2 Paper Tray Characteristics
*1: B Zone/Fresh Paper, P Paper
*1: B Zone/Fresh Paper, P Paper
6.1.14.3 Remaining Paper Amount Detection
• When the power is turned OFF during liftup, if the power is turned ON again without
removing the Tray, and the Tray is inserted again while the Bottom Plate has not dropped,
the remaining paper amount cannot be detected correctly.
Extra
Heavy-
weight
Heavy-
weight
Gloss
13/13 NA 5/5 NA 7/7 NA 7/7 NA 7/7 NA
Table 1
Paper
Type
Settings
216.0 mm or
shorter in the
SS direction
and 210.0 mm
or longer in
the FS
direction
216.1 mm to
297.2 mm in
the SS
direction
297.3 mm to
364.1 mm in
the SS
direction
364.2 mm to
432.0 mm in
the SS
direction
(A3S/11x17S)
A4 LEF
8.5x11 LEF
B5 LEF
A5 SEF
B5 SEF
5.5x8.5 SEF
A4 SEF
8.5x11 SEF
B4 SEF
8.5x13
SEF8.5x14
SEF8.5x13.4
SEF
A3 SEF
11x17 SEF
1
Sided
2
Sided
1
Sided
2
Sided
1
Sided
2
Sided
1
Sided
2
Sided
1
Sided
2
Sided
Table 1
IOT/
TM
Tray
No.
Supported
Paper
(Standard Size)
Supported
Paper
(Non-Standard
Size) (W x L)
mm
Supporte
d Paper
Weight
(gsm)
Storage
Capacity
*1 Remarks *3
IOT Tray 1 Min: A5 SEF,
5.5x8.5"
Max: A3 SEF,
11x17" SEF
Non-Standard
Sizes not sup-
ported
60-90 250 Stack height: 27
mm
MSI Min: A5 SEF
Max: A3 SEF,
11x17" SEF
Min: 127x98 *2
Max: 297x432
60-216 100 Stack height: 10
mm
STM Tray 2 Min: A5 SEF
Max: A3 SEF,
11x17" SEF
Non-Standard
Sizes not sup-
ported
60-216 500 Stack height: 54
mm
2TM Tray 3 Min: A5 SEF
Max: A3 SEF,
11x17" SEF
Non-Standard
Sizes not sup-
ported
60-216 500 Stack height: 54
mm
Tray 4 Min: A5 SEF
Max: A3 SEF,
11x17" SEF
Non-Standard
Sizes not sup-
ported
60-216 500 Stack height: 54
mm
Table 2
Target Tray Detection & Notification Remarks
Tray 1-4 None
MSI None
