Xerox WorkCentre 5024 Service Manual

06/2014
6-19
WC 5022/5024
6.1.25 Scan Feature Specifications
General
Version 1.0
6.1.25 Scan Feature Specifications
*1: The scan speed differs depending on the document.
*1: The scan speed differs depending on the document.
6.1.26 Fax Feature
6.1.26.1 Fax Feature
6.1.26.2 Direct Fax Feature
Table 1
Item Contents
Type Color Scanner
Scan Size Conforms with the Basic Feature/Copy Feature
Scan Resolution Monochrome: 600x600 dpi, 400x400 dpi, 300x300 dpi, 200x200
dpi Color: 300x300 dpi, 200x200 dpi
Scan Gradation 8 bit input and 8 bit output for each color of RGB
Document Scan Speed*1 Monochrome: 18 sheets/min
[When using Xerox standard document (A4 LEF), 200 dpi, Scan
to PC (TWAIN: USB)]
Color: 4 sheets/min
[When using Xerox standard document (A4 LEF), 200 dpi]
Interface Standard: USB 1.1 / 2.0
Options: Ethernet 100 BASE-TX/10 BASE-T
Scan to PC(TWAIN: USB) Output Format:Monochrome/Color: depends on application
Supported OS:
Windows XP, Windows XP Professional x64 Edition Windows
Server 2003, Windows Server 2003 x64 Editions Windows
Vista, Windows Vista 64 bit Windows Server 2008 (x86), Win-
dows Server 2008 (x64) Windows Server 2008 R2 Windows 7,
Windows 7 64 bit Windows 8, Windows 8 64 bit Windows Server
2012 (x64)
Scan to PC(SMB) Supported Protocols: TCP/IP (SMB)
Output Format:
Monochrome: TIFF (MultiPages), PDF Color: JPEG, PDF
Scan to E-mail Supported Protocols: TCP/IP (SMTP)
Output Format:
Monochrome: TIFF (MultiPages), PDF Color: JPEG, PDF
Table 1
Item Contents
Sent document size Max: A3
Recording paper size Max: A3, Min: A4
Transmission time 3 s or faster
Communication Mode Super G3 / G3 ECM / G3 (ITU-T)
Scan line density Standard: 8x3.85 lines/mm, 200x100 dpi
High Quality: 8x7.7 lines/mm, 200x200 dpi
Superfine (400 dpi): 16x15.4 lines/mm, 400x400 dpi
Encoding Method MH, MR, MMR, JBIG
Communication speed G3: 33.6 / 31.2 / 28.8 / 26.4 / 24.0 / 21.6 / 19.2 / 16.8 / 14.4 /
12.0 / 9.6 / 7.2 / 4.8 / 2.4 kbps
Applicable lines PBX, Facsimile Communication Network (PSTN)
Table 2
Item Contents
Sent document size A3, B4, A4
Communication speed According to the Fax Function
Communication resolution Standard: 200x100 dpi (7.9x3.9 dots/mm)
High Qualist: 200x200 dpi (7.9x7.9 dots/mm)
Superfine: 400x400 dpi (15.7x15.7 dots/mm)
Applicable lines According to the Fax Function
Supported OS Windows XP, Windows XP Professional x64 Edition Windows
Server 2003, Windows Server 2003 x64 Editions Windows
Vista, Windows Vista 64 bit Windows Server 2008 (x86), Win-
dows Server 2008 (x64) Windows Server 2008 R2
Windows 7, Windows 7 64 bit Windows 8, Windows 8 64 bit
Windows Server 2012 (x64)

Xerox WorkCentre 5024 Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	14 s
Print speed (black, normal quality, A3)	12 ppm
Print speed (black, normal quality, A4/US Letter)	24 ppm
Duplex print speed (black, normal quality, A4/US Letter)	17 ppm
Copy speed (black, normal quality, A3)	12 cpm
Copy speed (black, normal quality, A4)	24 cpm
Scan to	E-mail, PC
Scan drivers	TWAIN
Scanner type	ADF scanner
Scan speed (black)	22 ppm
Scan speed (color)	13 ppm
Faxing	-
Modem speed	33.6 Kbit/s
Printing colors	Black
Maximum duty cycle	25000 pages per month
Recommended duty cycle	0 - 25000 pages per month
Number of print cartridges	2
Wi-Fi	No
Email protocols	SMTP
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Internal memory	256 MB
Standard interfaces	USB 2.0
Display	LCD
Product color	Gray
Market positioning	Business
Windows operating systems supported	Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64
Paper input type	Paper tray
Total input capacity	350 sheets
Total output capacity	- sheets
Maximum input capacity	1850 sheets
Total number of input trays	5
Paper tray media types	Labels, Plain paper, Recycled paper
Paper tray media weight	60 - 90 g/m²
ISO A-series sizes (A0...A9)	A3, A4
ISO B-series sizes (B0...B9)	B4, B5
Maximum ISO A-series paper size	A3
Power consumption (average operating)	- W
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	574 mm
Width	594.3 mm
Height	581.6 mm
