06/2014
6-20
WC 5022/5024
6.1.27 Document Feeder (DADF)
Version 1.0
General
6.1.27 Document Feeder (DADF)
• CPS (Local) is an option
*1: Xerox P Paper
6.1.28 Billing Counter
6.1.28.2 Billing Counter
1. Type of Billing Counter
• The following counters are provided for this product.
2. Format of Billing Counter
• Including the backup, there are 2 sets of installed Billing Counters (that are defined
in Type of Billing Counter). These Billing Counters are installed in the NVMs of the
ESS / MCU PWB.
3. Billing Meter
a. Billing Meter Display
• Meter 1: Equivalent to the total number of sheets for Copy Counter, Print
Counter, and Fax Counter
• Meter 2: Equivalent to the number of sheets for Copy Counter
• Meter 3: Equivalent to the number of sheets for Print Counter
• Meter 4: Equivalent to the number of sheets for Fax Counter
• Meter 5: Total number of sheets for Large Size
Table 1
Item Contents
Type of Document Feeder Duplex Auto Document Feeder
Originals Size/Type Max: A3, 11x17"
Min: A5
38 to 128 g/m2 (Duplex: 50 to 128 g/m2)
Document capacity *1 110 sheets
Document replacement
speed
(A4 LEF 1 Sided Copy)
WC 5022: 22 sheets/min
WC 5024: 24 sheets/min
Size/Weight Width: 540 mm or shorter x Depth: 492 mm or shorter x Height:
115 mm or shorter
6.7 kg or lighter
Table 1 (Counter Groups)
Type Description
Group I This counter group had been defined as technical standard to fulfill the
billing needs by Operation Mode (by service type, such as Copy) and
Output Color
Group II The large size counter function
Table 2 (Counter Type)
Type Description Range Remarks
BW Copy Counter The total number of printed
impressions that had been out-
put by the machine as Copy Jobs
0~10,000,000 All Report types are
counted as Print.
BW Print Counter The total number of printed
impressions for Print Jobs and
Reports
0~10,000,000
BW Fax Counter The total number of printed
impressions for Fax Jobs
0~10,000,000
BW Large Size
Counter
The total number of large size
impressions for Copy/Print/Fax
Print
0~10,000,000
To Next Page
