06/2014
6-27
WC 5022/5024
6.3.2.1 DADF Output Component Check List
General
Version 1.0
6.3.2.1 DADF Output Component Check List
6.3.2.2 IIT Output Component Check List
6.3.2.4 IOT Ouput Component Check List
Table 1 DADF Output Component Check List
Chain-Link Component Name Description
005-004 DADF FEED MOTOR
CW 82.5 mm/s
Drives the DADF FEED MOTOR at 82.5 mm/s in CW direction.
Turns ON for 50 s -> Auto OFF
005-005 DADF FEED MOTOR
CW 110.0 mm/s
Drives the DADF FEED MOTOR at 110.0 mm/s in CW direction.
Turns ON for 50 s -> Auto OFF
005-008 DADF FEED MOTOR
CW 165.0 mm/s
Drives the DADF FEED MOTOR at 165.0 mm/s in CW direction.
Turns ON for 50 s -> Auto OFF
005-010 DADF FEED MOTOR
CW 220.0 mm/s
Drives the DADF FEED MOTOR at 220.0 mm/s in CW direction.
Turns ON for 50 s -> Auto OFF
005-046 DADF FEED MOTOR
CCW 82.5 mm/s
Drives the DADF FEED MOTOR at 82.5 mm/s in CCW direction.
Turns ON for 50 s -> Auto OFF
005-047 DADF FEED MOTOR
CCW 110.0 mm/s
Drives the DADF FEED MOTOR at 110.0 mm/s in CCW direction.
Turns ON for 50 s -> Auto OFF
005-048 DADF FEED MOTOR
CCW 165.0 mm/s
Drives the DADF FEED MOTOR at 165.0 mm/s in CCW direction.
Turns ON for 50 s -> Auto OFF
005-049 DADF FEED MOTOR
CCW 220.0 mm/s
Drives the DADF FEED MOTOR at 220.0 mm/s in CCW direction.
Turns ON for 50 s -> Auto OFF
005-062 DADF FEED CLUTCH Drives the DADF FEED CLUTCH.
Turns ON for 3 s -> Auto OFF
005-072 EXIT NIP RELEASE SOLENOID Turns ON the EXIT NIP RELEASE SOLENOID.
Turns ON for 3 s -> Auto OFF
005-083 DOCUMENT READY Turns ON the DOCUMENT READY signal.
005-088 Image Area ON Turns ON the Image Area signal for 5 s.
005-098 TAKEAWAY CLUTCH Turns ON the TAKEAWAY CLUTCH for 3 s.
Table 1 IIT Output Component Check List
Chain-Link Component Name Description Remarks
062-002 IIT Exposure Lamp Turns ON the IIT Exposure Lamp.
Turns the Lamp ON for 180 s -> Auto OFF
Will also turn OFF when Stop is instructed before Auto
OFF.
062-005 CARRIAGE MOTOR (Scan direction) Moves it 50 mm from current position in Scan direction -> Auto OFF Will not accept Stop instruction before Auto OFF.
062-006 CARRIAGE MOTOR (Return direction) Moves it 50 mm from current position in Return direction -> Auto
OFF
Will not accept Stop instruction before Auto OFF.
062-091 Exchange to DADF Turns ON the document exchange command signal to the DADF.
Table 1 IOT Ouput Component Check List
Chain-Link Component Name Description
042-001 MAIN DRIVE MOTOR On Drives the MAIN DRIVE MOTOR.
To Next Page
