06/2014
6-28
WC 5022/5024
6.3.2.4 IOT Ouput Component Check List
Version 1.0
General
042-002 NOHAD FAN (High Speed) Drives the NOHAD FAN at high speed.
042-003 NOHAD FAN (Low Speed) Drives the NOHAD FAN at low speed.
061-001 ROS Motor On Turns ON the Polygon Motor.
071-001 REGI. CLUTCH On Turns ON the REGI CLUTCH.
071-002 DUPLEX CLUTCH On Turns ON the DUPLEX CLUTCH.
071-003 INVERT MOTOR (CW Phase1-2) Drives the INVERT MOTOR in CW Phase 1-2.
071-004 INVERT MOTOR (CW Phase2) Drives the INVERT MOTOR in CW Phase 2.
071-005 INVERT MOTOR (CCW Phase1-2) Drives the INVERT MOTOR in CCW Phase 1-2.
071-006 INVERT MOTOR (CCW Phase2) Drives the INVERT MOTOR in CCW Phase 2.
072-001 TRAY 1 FEED CLUTCH On Turns ON the TRAY 1 FEED CLUTCH.
072-002 TRAY 2 FEED/LIFT UP MOTOR (Feed) Performs the Paper Feed operation using TRAY 2 FEED/LIFT UP MOTOR.
072-003 TRAY 3 FEED/LIFT UP MOTOR (Feed) Performs the Paper Feed operation using TRAY 3 FEED/LIFT UP MOTOR.
072-004 TRAY 4 FEED/LIFT UP MOTOR (Feed) Performs the Paper Feed operation using TRAY 4 FEED/LIFT UP MOTOR.
072-005 STM TAKEAWAY ROLL CLUTCH On Turns ON the STM TAKEAWAY ROLL CLUTCH.
072-006 2TM TAKEAWAY ROLL CLUTCH On Turns ON the 2TM TAKEAWAY ROLL CLUTCH.
072-007 STM TAKEAWAY MOTOR On Drives the STM TAKEAWAY MOTOR.
072-008 2TM TAKEAWAY MOTOR On Drives the 2TM TAKEAWAY MOTOR.
072-009 TRAY 2 FEED/LIFT UP MOTOR (Lift Up) Performs the Tray Lift Up operation using TRAY 2 FEED/LIFT UP MOTOR.
072-010 TRAY 3 FEED/LIFT UP MOTOR (Lift Up) Performs the Tray Lift Up operation using TRAY 3 FEED/LIFT UP MOTOR.
072-011 TRAY 4 FEED/LIFT UP MOTOR (Lift Up) Performs the Tray Lift Up operation using TRAY 4 FEED/LIFT UP MOTOR.
072-014 MSI FEED CLUTCH On Turns ON the MSI FEED CLUTCH.
091-001 Xero Combination Carries out combined operation of the following components.
• BCR AC Bias On
• BCR DC Bias On
• DEVE DC Bias On
• MAIN DRIVE MOTOR On
• BTR +Bias On
091-002 BCR AC Bias On Turns ON the BCR AC Bias.
091-003 BCR DC Bias On Turns ON the BCR DC Bias.
091-004 DEVE DC Bias On Turns ON the DEVE DC Bias.
091-005 BCR AC DC Bias On Turns ON the AC and DC BCR Bias.
092-001 TONER DISPENSE MOTOR On Drives the TONER DISPENSE MOTOR.
094-001 BTR+ Bias On Turns ON the BTR positive bias.
094-002 BTR- Bias On Turns ON the BTR negative bias.
Table 1 IOT Ouput Component Check List
Chain-Link Component Name Description
To Next Page
