WC 5022/5024
6.3.3.2 Analog Monitor List
General
Version 1.0
6.3.3.2 Analog Monitor List
Table 1 Analog Monitor List
Chain-Link Component Name Description
072-050 TRAY 1 PAPER SIZE Sensor Displays the AD value for Tray 1 paper size.
For the relationsip between the Tray 1 paper size and the AD value, refer to "BSD Chain 7.1" in Chapter 7
072-051 TRAY 2 PAPER SIZE Sensor Displays the AD value for Tray 2 paper size.
For the relationsip between the Tray 2 paper size and the AD value, refer to "BSD Chain 7.1" in Chapter 7
072-052 TRAY 3 PAPER SIZE Sensor Displays the AD value for Tray 3 paper size.
For the relationsip between the Tray 3 paper size and the AD value, refer to "BSD Chain 7.1" in Chapter 7
072-053 TRAY 4 PAPER SIZE Sensor Displays the AD value for Tray 4 paper size.
For the relationsip between the Tray 4 paper size and the AD value, refer to "BSD Chain 7.1" in Chapter 7
092-050 ATC_SNR Displays the AD value that was detected by the ATC SENSOR.
• AD Value Retrieval Range: 0~999
• Normal Range: 100~900
• Failure Determination Level: Out of the above range
010-050 Heat Roll STS Center Displays the AD value for the temperature that was detected by the FUSING UNIT CENTER THERMISTOR.
• AD Value Retrieval Range: 0~1023
• Normal Environment: 488 (210 degrees C) to 760 (145 degrees C)
• High Temperature Failure Determination Level: when 362 and lower [245 degrees C and higher] is
detected continuously for the specified time.
010-051 Heat Roll STS Rear Displays the AD value for the temperature that was detected by the FUSING UNIT REAR THERMISTOR.
• AD Value Retrieval Range: 0~1023
• Normal Environment: 490 (210 degrees C) to 761 (145 degrees C)
• High Temperature Failure Determination Level: when 292 and lower [270 degrees C and higher] is
detected continuously for the specified time.
To Next Page
