06/2014
6-32
WC 5022/5024
6.3.4.4 IOT HFSI List
Version 1.0
General
6.3.4.4 IOT HFSI List
Table 1 IOT HFSI List
Chain-Link HFSI Name Life Value Count Condition Description
950-800 BTR Unit (X'fer) 100,000 Counts up when paper passes through the Fusing Unit Exit Sensor. The count
value is determined based on multiples of paper length in 216 mm.0 mm <
Paper Length <= 216 mm: 1 Count Up216 mm < Paper Length <= 432 mm: 2
Counts Up
To clear the counter, enter the HFSI Counter Read / Clear Mode and select
[Clear] -> [Start] to clear it to '0'.
This can count up to the maximum of 1,000,000 and the maximum value is
retained until the counter is cleared.
BTR Unit ON Count (PV conversion)
950-801 Fusing Unit 17,500,000 Counts up when paper passes through the Fusing Unit Exit Sensor.
The conversion value is calculated with 1 sheet of A4 L being equivalent to a
value of 100.
Count value = (the rest of the former counter up + paper length)[0.1mm]/210
To clear the counter, enter the HFSI Counter Read / Clear Mode and select
[Clear] -> [Start] to clear it to '0'.
This can count up to the maximum of 9,999,999 and the maximum value is
retained until the counter is cleared.
No. of sheets transported through the Fusing
Unit
(A4 LEF conversion value)
950-802 MSI Feed Roll/Nudger Roll/Retard
Pad
50,000 Counts up at feeding from MSI.
To clear the counter, enter the HFSI Counter Read / Clear Mode and select
[Clear] -> [Start] to clear it to '0'.
This can count up to the maximum of 999,999 and the maximum value is
retained until the counter is cleared.
No. of sheets fed to MSI Feed Roll, MSI
Nudger Roll, and MSI Retard Pad
950-803 Tray1 Feed Roll/Retard Pad 50,000 Counts up at feeding from Tray 1.
To clear the counter, enter the HFSI Counter Read / Clear Mode and select
[Clear] -> [Start] to clear it to '0'.
This can count up to the maximum of 999,999 and the maximum value is
retained until the counter is cleared.
No. of sheets fed to Tray 1 Feed Roll and
Tray 1 Retard Pad.
950-804 Tray2 Feed/Retard/Nudger Roll 300,000 Counts up at feeding from Tray 2.
To clear the counter, enter the HFSI Counter Read / Clear Mode and select
[Clear] -> [Start] to clear it to '0'.
This can count up to the maximum of 999,999 and the maximum value is
retained until the counter is cleared.
No. of sheets fed through Tray 2 Feed Roll,
Tray 2 Retard Roll, and Tray 2 Nudger Roll
950-805 Deodorant Filter - Not used
950-807 Drum_Cycle_Counter [22PPM]
343K Cycle
(Ref 66K PV)
[24PPM]
343K Cycle
(Ref 78K PV)
Counts up at each 0.1 cycle.
This can count up to the maximum of 8,000,000 and the maximum value is
retained until the counter is cleared.
950-808 Tray3 Feed/Retard/Nudger Roll 300,000 Counts up at feeding from Tray 3.
To clear the counter, enter the HFSI Counter Read / Clear Mode and select
[Clear] -> [Start] to clear it to '0'.
This can count up to the maximum of 999,999 and the maximum value is
retained until the counter is cleared.
No. of sheets fed through Tray 3 Feed Roll,
Tray 3 Retard Roll, and Tray 3 Nudger Roll
To Next Page
