6.3.4.5 IOT HFSI List - System Administrator Mode
Version 1.0
General
6.3.4.5 IOT HFSI List - System Administrator Mode Version
Purpose
This provides a function to initialize the HFSI Counter and Replacement Flag in the System
Administrator Mode, which is limited to the Periodic Replacement Parts that a User can
replace.
Procedure
1. Enter the System Administrator Mode.
a. Press <Log In/Out> for 4 seconds or longer.
b. Use the keypad to enter the Password [11111] *1 and select [OK].
NOTE: *1 Default Value
2. Use <Up>/<Down> to select [System Settings] and then select [OK] or [->].
3. Use <Up>/<Down> to select [Maintenance] and then select [OK] or [->].
4. Input the following number for the applicable parts and then press <Start> to display the
[Part Name] and [Current Value]. Pressing <Start> again clears the counter.
*1: 752133 is not an HSFI Counter. It is something used for clearing the Replacement
Flag in the event of a replacement. The Current Value displays '0'.
5. Check the value using Step 4 as needed.
6. Exit from the System Administrator Mode.
a. Press <Log In/Out>. *2
*2: If any of the above parts had been cleared, the machine will reboot upon exiting from
the System Administrator Mode.
Table 1
Number Component Name
950800 X'fer (BTR Unit)
950801 Fusing Unit Assy
950802 MSI Feed
950803 Tray 1 Feed
950804 Tray 2 Feed
950805 Deodorant Filter
950806 VOC Filter
950807 Drum Cartridge
950808 Tray 3 Feed
950809 Tray 4 Feed
752133 *1 Manual Toner Change
